Static Field Shelters

Whether it is in the hot sun, cold winds or driving rain, a Prime static field shelter can provide protection for your horses. Available in a variety of standard sizes, from 3.6m x 3.6m to 12m x 3.6m, with one two or three openings.

Manufactured to Order – Variety of Sizes

All of our buildings are individually manufactured to order, so we can adapt the sizes and specifications to suit your specific requirements.

Static field shelters do require some groundwork preparation and the most economical option is to use railway sleepers to create a perimeter base for the walls to sit on.  Alternatively, a concrete base with a single course of bricks.  For each option, on receipt of the deposit, we will provide you with a plan for your ground worker to follow.

Our static field shelters can be installed as stand alone, free-standing buildings or incorporated within your stable block.

Static Field Shelters
  • Shelter, Store & Covered Area View
  • Double Static Shelter View
  • L Shape Fixed Field Shelter View
  • Double Fixed Shelter View
  • Double Field Shelter - Clay Tile Roof View



Prime Range Stables Specification

Shiplap Cladding

Top grade redwood shiplap cladding 16mm x 150mm, fixed with 50mm sheradised ring shank nails.

Framework

The frameworks are manufactured with kiln dried timber, 47mm x 75mm. All timber is regularised and strength graded for structural use to C16-C24.

Kickboarding

All stables are kickboarded as standard to a height of 1.2m high with exterior grade 12mm WISA Spruce plywood – multiple 5 layered, for structural integrity.

Roof

Black Onduline roof with galvanised ridge.  Also available in green, brown or red.  Standard roof pitch is 15 degrees.  Purlins 100mm x 47mm, 125mm x 47mm, 100mm x 100mm.  Fitted to Onduline specification.

Guttering

100mm half round black guttering with 50mm round downpipes are fitted as standard to the front of all buildings.  Back guttering is available.

Preservative

Buildings are treated with an animal friendly preservative product to a golden brown finish before leaving our workshop.

Other Details

All buildings are 2.2m to the eaves and approximately 2.9m to the ridge, when erected on one course of bricks.  Overhang (if included) at 0.9m deep, supplied unlined.  Back and end panels come with a weather prevention DPC skirt to eliminate water penetrating the base of the walls.  All internal roof trusses are open to aid ventilation.
