PRIME RANGE AMERICAN BARNS

The Prime Range has been designed to provide you with a high quality, value for money American barn. A robust barn that includes all of the features and benefits you would expect your barn and stables to have.

Our Prime Range is the range we have supplied from the start, of course as with anything, there have been changes and improvements made along the way, but it still remains our most popular range.

Provide Shelter | Everything Under One Roof | Work in All Weather

Prime Range American Barn Specifications

Shiplap Cladding

Top grade redwood shiplap cladding 16mm x 150mm, fixed with 50mm sheradised ring shank nails.

Framework

The frameworks are manufactured with kiln dried timber, 47mm x 75mm. All timber is regularised and strength graded for structural use to C16-C24.

Kickboarding

All stables are kickboarded as standard to a height of 1.2m high with exterior grade 12mm WISA Spruce plywood – multiple 5 layered, for structural integrity.

Roof

Black Onduline roof with galvanised ridge.  Also available in green, brown or red.  Clear roof sheet included above each box.  Standard roof pitch is 15 degrees.  Purlins 100mm x 47mm, 125mm x 47mm, 100mm x 100mm.  Fitted to Onduline specification.

Doors

Bottom doors only.  Manufactured from 125mm x 25mm tongue, groove and v-jointed timber, ledged and braced.  Doors are lined with exterior grade plywood to give an overall thickness of 50mm.  Stable door size 1.1m wide x 1.3m high.  Top door 0.8m high.  Doors are furnished with 1 x strong anti-chew strip, 1 x heavy duty kick-over latch and 1 x 225mm brenton bolt, 1 x 150mm cabin hook and 1 pair of 600mm heavy duty tee hinges. 2.4m wide double doors at each end.

Guttering

100mm half round black guttering with 50mm round downpipes are fitted as standard to both sides.

Windows

One sliding window is fitted to the rear of each stable.

Preservative

Buildings are treated with an animal friendly preservative product to a golden brown finish before leaving our workshop.

Internal Partitions

Timber frame internal sections at 2.2m high.  Front sections are fully clad with top grade redwood shiplap.  All stables are kickboarded internally to 1.2m high with very strong 12mm exterior grade plywood.  Front walls include a 1.17m wide grill.

Other Details

All Prime barns are 2.2m to the eaves and a 10.2m deep barn is approximately 3.7m to the ridge, when erected on one course of bricks.  Two gable end vents are included at each end.
